| PartNumber | LAJ080W001A |
| Znamka | TPO |
| Velikost | 8.0 |
| Aplikacija | CNS |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | TPO |
| panelni model | LAJ080W001A |
| vrsta plošče | LTPS TFT-LCD , LCM |
| velikost plošče | 8.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 174×104.4 mm |
| površino | |
| svetlost | |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193150% |
| odzivni čas | 4.5/7.5 (Typ.)(Tr/Td) |
| vidni kot | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 60 pins |
| aplikacija | CNS |
