| PartNumber | AM-640480GJTNQW-TA0H |
| Znamka | AMPIRE |
| Velikost | 5.7 |
| Aplikacija | IA |
| Resolucija | 640×480 |
| Sestava | LCM |
| Svetlost | 425 |
| CR | 250:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | AMPIRE |
| panelni model | AM-640480GJTNQW-TA0H |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.7 inch |
| resolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 115.2×86.4 mm |
| oris | 127×98.43×9.84 mm |
| površino | |
| svetlost | 425 cd/m² (Typ.) |
| kontrastno razmerje | 250:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193150% |
| odzivni čas | 50 (Typ.)(Tr+Td) |
| vidni kot | 70/70/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (1 ch, 8-bit), 20 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
