| PartNumber | AM-1024600K7TMQW-T19H |
| Znamka | AMPIRE |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 1024×600 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | AMPIRE |
| velikost diagonale | 7.0 inch |
| slikovnih pik | 1024(RGB)×600 [WSVGA] 169PPI |
| aktivno območje | 153.6(H)×90(V) mm |
| svetilnost | 425 cd/m² (Typ.) |
| smer pogleda | 6 o'clock |
| vidni kot | 75/75/70/75 (Typ.)(CR≥10) |
| podpira barvo | 16.7M |
| utež | TBD |
| hitrost sličic | 60Hz |
| model | AM-1024600K7TMQW-T19H |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 165.5(H)×104.44(V) ×10.81(D) mm |
| kontrastno razmerje | 700:1 (Typ.) (TM) |
| odzivni čas | 20/20 (Typ.)(Tr/Td) |
| način delovanja | TN, Normally White, Transmissive |
| Izvor svetlobe | WLED [5S3P] , 30K hours , With LED Driver |
| namenjen za | Industrial |
| plošča na dotik | PCAP |
