| PartNumber | AM-1024600K7TMQW-T04H |
| Znamka | AMPIRE |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 1024×600 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 262K |
| Osvetlitev ozadja | 8S3P |
| Vmesnik | |
| znamka plošče | AMPIRE |
| velikost plošče | 7.0" |
| resolucija | 1024(RGB)×600, WSVGA, 169PPI |
| prikazno območje | 153.6(W)×90(H) mm |
| velikost obrisa | 165.5(W)×104.44(H) ×10.81(D) mm |
| svetlost | 850 cd/m² (Typ.) |
| vidni kot | 75/75/70/75 (Typ.)(CR≥10) |
| najboljši pogled na | 6 o'clock |
| barve zaslona | 262K |
| pogostost | 60Hz |
| utež | TBD |
| panelni model | AM-1024600K7TMQW-T04H |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | - |
| kontrastno razmerje | 700:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 20/20 (Typ.)(Tr/Td) |
| tip svetilke | 8S3P WLED , 50K hours , With LED Driver |
| zaslon na dotik | PCAP |
| aplikacija | Industrial |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| LB070WV4-SD01 | LG Display | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
