| PartNumber | AM-1024600ITZQW-T00H |
| Znamka | AMPIRE |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1024×600 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | AMPIRE |
| velikost zaslona | 10.1 inch |
| število slikovnih pik | 1024(RGB)×600 (WSVGA) 117PPI |
| aktivna površina (mm) | 222.72 × 125.28 (H×V) |
| površina okvirja (mm) | - |
| svetilnost | 465 cd/m² (Typ.) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| barvna globina | 262K/16.7M 70% NTSC |
| masa | - |
| hitrost osveževanja | 60Hz |
| vrsto signala | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| napajanje z napetostjo | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ime modela | AM-1024600ITZQW-T00H |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 255 × 165.8 (H×V×D) |
| zdravljenje | Antiglare, Hard coating |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| odgovor | 12/28 (Typ.)(Tr/Td) ms |
| način dela | IPS, Normally Black, Transmissive |
| osvetlitev ozadja | WLED , 50K hours , No Driver |
| uporablja za | Industrial |
| zaslon na dotik | PCAP |
