| PartNumber | AM-1024600DTZQW-TA6H |
| Znamka | AMPIRE |
| Velikost | 7.0 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1024×600 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AMPIRE |
| model | AM-1024600DTZQW-TA6H |
| velikost diagonale | 7.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1024(RGB)×600 [WSVGA] 170PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 154.221(H)×85.92(V) mm |
| obris dim. | 164.9(H)×128(V) ×12.6(D) mm |
| svetilnost | 850 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 13/15 (Typ.)(Tr/Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | IPS, Normally Black, Transmissive |
| podpira barvo | 16.7M 58% NTSC |
| Izvor svetlobe | WLED , 50K hours , With LED Driver |
| utež | - |
| namenjen za | Industrial Outdoor High Brightness |
| hitrost sličic | 60Hz |
| plošča na dotik | PCAP |
| tip vmesnika | LVDS (1 ch, 8-bit) , 20 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
