| PartNumber | AM-1024600DTZQW-TA0H |
| Znamka | AMPIRE |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 1024×600 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka plošče | AMPIRE |
| velikost plošče | 7.0" |
| resolucija | 1024(RGB)×600, WSVGA, 170PPI |
| prikazno območje | 154.221(W)×85.92(H) mm |
| velikost obrisa | 184(W)×128(H) ×12.6(D) mm |
| svetlost | 425 cd/m² (Typ.) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 16.7M 58% NTSC |
| pogostost | 60Hz |
| utež | - |
| panelni model | AM-1024600DTZQW-TA0H |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | - |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| način prikaza | IPS, Normally Black, Transmissive |
| odzivni čas | 13/15 (Typ.)(Tr/Td) |
| tip svetilke | WLED , 30K hours , With LED Driver |
| zaslon na dotik | PCAP |
| aplikacija | Industrial |
