| PartNumber | ACX425AKM |
| Znamka | SONY |
| Velikost | 3.7 |
| Aplikacija | MPH |
| Resolucija | 480×800 |
| Sestava | LCM |
| Svetlost | 320 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | SONY |
| panelni model | ACX425AKM |
| vrsta plošče | LTPS TFT-LCD , LCM |
| velikost plošče | 3.7 inch |
| resolucija | 480(RGB)×800 , WVGA |
| način prikaza | Normally Black, Transmissive |
| aktivno območje | 48.24×80.4 mm |
| oris | 53.9×90 mm |
| površino | Hard coating (3H) |
| svetlost | 320 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193190% |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S1PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit) + SPI, 40 pins |
| vhodna napetost | 2.6/2.6V (Typ.)(VDD/AVDD) |
| aplikacija | MPH |
| ACX425AKM | SONY | 3.7 | 480×800 |
| ACX435AKN-7 | SONY | 4.5 | 800×1280 |
| ACX450AKN-7 | JDI | 5.0 | 1080×1920 |
| ACX465AKM-7 | JDI | 5.9 | 1080×1920 |
| HVA37WV1-D01 | HYDIS | 3.7 | 480×800 |
| LS037V3DX02 | SHARP | 3.7 | |
| LS037V7DD05 | SHARP | 3.7 | 480×640 |
| LS037V7DD06 | SHARP | 3.7 | 480×640 |
| LS037V7DW03 | SHARP | 3.7 | 480×640 |
| LS037V7DW03B | SHARP | 3.7 | 480×640 |
| AMCE002 | Samsung | 2.4 | 240×320 |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| CLAF050LG41 TXX | CPT | 5.0 | 540×960 |
| CLAF055LA41 TXX | CPT | 5.5 | 540×960 |
| DLC0220KZG | Other | 2.2 | 320×320 |
| H546DLB01.1 | AUO | 5.5 | 1080×1920 |
| LS030B3UX07 | SHARP | 3.0 | 240×400 |
| LS050T1SX10 | SHARP | 5.0 | 1080×1920 |
| LS063K3SX01 | SHARP | 6.3 | 720×1280 |
| TM032PDZ17 | Tianma | 3.2 | 320×480 |
