| PartNumber | A102VW01 V7 |
| Znamka | AUO |
| Velikost | 10.2 |
| Aplikacija | CNS |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 400:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TTL |
| znamka plošče | AUO |
| panelni model | A102VW01 V7 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 10.2 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 222×133.2 mm |
| oris | 235×145.9 mm |
| površino | Antiglare |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 400:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 12/18 (Typ.)(Tr/Td) |
| vidni kot | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 60 pins |
| vhodna napetost | 3.3/8.8/15/-7.0/3.6V (Typ.)(VCC/AVDD/VGH/VGL/VCOM) |
| aplikacija | CNS |
