| PartNumber | YX090DKN01.0 |
| Znamka | SEBO |
| Velikost | 9.0 |
| Aplikacija | CNS |
| Resolucija | 1280×720 |
| Sestava | LCM |
| Svetlost | 800 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | SEBO |
| panelni model | YX090DKN01.0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 9.0 inch |
| resolucija | 1280(RGB)×720 , WXGA |
| način prikaza | Normally Black, Transmissive |
| aktivno območje | 198.72×111.78 mm |
| oris | 210.7×126.8 mm |
| površino | Antiglare |
| svetlost | 800 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193170% |
| odzivni čas | TBD |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 8-bit), 40 pins |
| vhodna napetost | 3.3/3.3V (Typ.)(VDD/VDDA) |
| aplikacija | CNS |
