| PartNumber | YX050800480WTIPS |
| Znamka | |
| Velikost | 5.0 |
| Aplikacija | CNS |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 500 |
| CR | 700:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | |
| panelni model | YX050800480WTIPS 0 Compatible model |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 108×64.8 mm |
| oris | 120.7×75.8 mm |
| površino | Antiglare |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 16.7M (8-bit) |
| odzivni čas | 10/10 (Typ.)(Tr/Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 8-bit) |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | CNS |
