| PartNumber | WG12232J-YYH-V#A |
| Znamka | Winstar |
| Velikost | 2.2 |
| Aplikacija | Industrial Instrumen |
| Resolucija | 122×32 |
| Sestava | STN-LCD, LCM |
| Svetlost | |
| CR | 3:1 |
| Barve | Monochrome |
| Osvetlitev ozadja | YG-LED |
| Vmesnik | 8-bit |
| znamka | Winstar |
| model | WG12232J-YYH-V#A |
| velikost diagonale | 2.2 inch |
| vrsta | STN-LCD, LCM |
| slikovnih pik | 122×32 57PPI |
| konfiguracijo | Rectangle |
| aktivno območje | 53.64(H)×15.64(V) mm |
| obris dim. | 80(H)×36(V) ×13.7(D) mm |
| območje okvirja | 60.0(H)×18.0(V) mm |
| zdravljenje | - |
| svetilnost | - |
| kontrastno razmerje | 3:1 (Typ.) (TM) |
| smer pogleda | 6 o'clock |
| odzivni čas | 150/150 (Typ.)(Tr/Td) |
| vidni kot | 30/30/20/40 (Max.)(CR≥2) |
| način delovanja | STN, Yellow/Green (Positive), Transflective |
| podpira barvo | Monochrome |
| Izvor svetlobe | YG-LED , 100K hours , W/O Driver |
| utež | - |
| namenjen za | Industrial Instruments & Meters |
| hitrost sličic | - |
| plošča na dotik | Without |
| tip vmesnika | 8-bit 6800/8080 parallel , 20 pins Pad |
| napajanje | 3.0V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
