| PartNumber | WG12232A-YYH-N#A |
| Znamka | Winstar |
| Velikost | 2.2 |
| Aplikacija | Industrial Instrumen |
| Resolucija | 122×32 |
| Sestava | LCM, STN-LCD |
| Svetlost | |
| CR | 3:1 |
| Barve | Monochrome |
| Osvetlitev ozadja | YG-LED |
| Vmesnik | |
| proizvajalec | Winstar |
| ime modela | WG12232A-YYH-N#A |
| velikost zaslona | 2.2 inch |
| vrsto zaslona | LCM, STN-LCD |
| število slikovnih pik | 122×32 57PPI |
| ureditev | Rectangle |
| aktivna površina (mm) | 53.64 × 15.64 (H×V) |
| obris (mm) | 84 × 44 × 13.7 (H×V×D) |
| površina okvirja (mm) | 60.0 × 18.0 (H×V) |
| zdravljenje | - |
| svetilnost | - |
| kontrastno razmerje | 3 : 1 (Typ.) (TM) |
| vidni kot | 30/30/20/40 (Max.)(CR≥2) |
| odgovor | 200/200 (Typ.)(Tr/Td) ms |
| dober pogled na | 6 o'clock |
| način dela | STN, Yellow/Green (Positive), Transflective |
| barvna globina | Monochrome |
| osvetlitev ozadja | YG-LED , 50K hours , No Driver |
| masa | - |
| uporablja za | Industrial Instruments & Meters |
| hitrost osveževanja | - |
| zaslon na dotik | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
