| PartNumber | WEO012864DR |
| Znamka | Winstar |
| Velikost | 0.96 |
| Aplikacija | Handheld & PDA H |
| Resolucija | 128×64 |
| Sestava | PM-OLED, OLED |
| Svetlost | |
| CR | |
| Barve | Mono(Red) |
| Osvetlitev ozadja | self |
| Vmesnik | 8-bit |
| znamka plošče | Winstar |
| panelni model | WEO012864DR |
| velikost plošče | 0.96" |
| vrsta plošče | PM-OLED, OLED |
| resolucija | 128×64, 149PPI |
| slikovnih pik | Rectangle |
| prikazno območje | 21.738(W)×10.858(H) mm |
| odprtina okvirja | 23.938(W)×12.058(H) mm |
| velikost obrisa | 26.7(W)×19.26(H) ×1.81(D) mm |
| površino | - |
| vidni kot | - |
| način prikaza | - |
| najboljši pogled na | Symmetry |
| odzivni čas | - |
| barve zaslona | Mono(Red) |
| tip svetilke | self |
| pogostost | - |
| zaslon na dotik | Without |
| voznik ic | COG Built-in SSD1306BZ |
| teža plošče | - |
| aplikacija | Handheld & PDA Healthcare Instruments & Meters |
| signalni vmesnik | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| vhodna napetost | 3.0V (Typ.) |
