| PartNumber | WEA012864DLPP3N00003 |
| Znamka | Winstar |
| Velikost | 0.96 |
| Aplikacija | Instruments & Meters |
| Resolucija | 128×64 |
| Sestava | OLED , PM-OLED |
| Svetlost | |
| CR | |
| Barve | Mono(Yellow) |
| Osvetlitev ozadja | self |
| Vmesnik | 4-wire |
| proizvajalec | Winstar |
| velikost zaslona | 0.96 inch |
| število slikovnih pik | 128×64 149PPI |
| aktivna površina (mm) | 21.74 × 10.86 (H×V) |
| površina okvirja (mm) | 23.94 × 12.06 (H×V) |
| vidni kot | - |
| dober pogled na | Symmetry |
| barvna globina | Mono(Yellow) |
| masa | - |
| hitrost osveževanja | - |
| seznam gonilnikov ic | Built-in COG SSD1306BZ |
| vrsto signala | 4-wire SPI, I²C , 8 pins PIN |
| napajanje z napetostjo | 3.3/5.0/7.5V (Typ.) |
| maks. ocene | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 80 °C |
| ime modela | WEA012864DLPP3N00003 |
| vrsto zaslona | OLED , PM-OLED |
| ureditev | Rectangle |
| obris (mm) | 38 × 28.5 × 4.37 (H×V×D) |
| zdravljenje | - |
| odgovor | - |
| način dela | - |
| osvetlitev ozadja | self |
| uporablja za | Instruments & Meters |
| zaslon na dotik | Without |
| IROP018-010-0128064-W | Other | 0.96 | 128×64 |
| L3P10Y-81G00 | Epson | 0.96 | 1400×1050 |
| OEL9M0083-B-E | Other | 0.96 | 128×64 |
| OEL9M0083-R-E | Other | 0.96 | 128×64 |
| OEL9M0083-W-E | Other | 0.96 | 128×64 |
| OEL9M0083-Y-E | Other | 0.96 | 128×64 |
| RGS10096096WR001 | RiTdisplay | 0.96 | 96×96 |
| RGS10128064WR010 | RiTdisplay | 0.96 | 128×64 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HSWEG01 | WiseChip | 0.96 | 128×64 |
