| PartNumber | V580DJ4-Q01 |
| Znamka | Innolux |
| Velikost | 58 |
| Aplikacija | TV Sets |
| Resolucija | 3840×2160 |
| Sestava | a-Si TFT-LCD , CELL |
| Svetlost | |
| CR | 5000:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | No |
| Vmesnik | V-by-One |
| znamka plošče | Innolux |
| velikost plošče | 58" |
| resolucija | 3840(RGB)×2160, UHD, 76PPI |
| prikazno območje | 1270.08(W)×721.44(H) mm |
| velikost obrisa | 1283.38(W)×734.69(H) ×1.32(D) mm |
| svetlost | 0 cd/m² |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| globina stekla | - |
| barve zaslona | 1.07B 71% NTSC |
| pogostost | 60Hz |
| voznik ic | COF Built-in 12 source chips |
| teža plošče | 2.80Kgs (Typ.) |
| signalni vmesnik | V-by-One 8 lane , 51 pins Connector |
| vhodna napetost | 12.0V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panelni model | V580DJ4-Q01 |
| vrsta plošče | a-Si TFT-LCD , CELL |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Hard coating (3H), Reflection 1.8% (Typ.) |
| kontrastno razmerje | 5000:1 (Typ.) (TM) |
| način prikaza | Super MVA, Normally Black, Transmissive |
| odzivni čas | 9.5 (Typ.)(G to G) |
| transmisivnost | 5.8% (Typ.)(with Polarizer) |
| tip svetilke | No B/L |
| zaslon na dotik | Without |
| aplikacija | TV Sets |
| V580DJ2-QS5 | Innolux | 58 | 3840×2160 |
| V580DK1-KS2 | Innolux | 58 | 3840×2160 |
| V580DK1-LS1 | Innolux | 58 | 3840×2160 |
| V580DK1-QS2 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 Rev.C8 | Innolux | 58 | 3840×2160 |
| V580DK2-LD1 | Innolux | 58 | 3840×2160 |
| V580DK2-QS1 | Innolux | 58 | 3840×2160 |
| V580HJ1-PD6 | Innolux | 58 | 1920×1080 |
