| PartNumber | TX20D16VM2BAA |
| Znamka | KOE |
| Velikost | 8.0 |
| Aplikacija | IA |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 200:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TTL |
| znamka plošče | HITACHI |
| panelni model | TX20D16VM2BAA |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 8.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 174×104.4 mm |
| oris | 189×120 mm |
| površino | Antiglare |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 200:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193160% |
| odzivni čas | 20/10 (Typ.)(Tr/Td) |
| vidni kot | 50/50/50/50 (Min.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | CMOS (1 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
