| PartNumber | TV101WXM-NU5 |
| Znamka | BOE |
| Velikost | 10.1 |
| Aplikacija | Pad & Tablet |
| Resolucija | 800×1280 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 7S4P |
| Vmesnik | |
| proizvajalec | BOE |
| velikost zaslona | 10.1 inch |
| število slikovnih pik | 800(RGB)×1280 (WXGA) 150PPI |
| aktivna površina (mm) | 135.36 × 216.576 (H×V) |
| površina okvirja (mm) | 137.76 × 220.076 (H×V) |
| svetilnost | 400 (Typ.)(cd/m²) |
| vidni kot | 85/85/85/85 (Min.)(CR≥10) |
| dober pogled na | Symmetry |
| barvna globina | 16.7M 60% NTSC |
| masa | 135g (Max.) |
| hitrost osveževanja | 60Hz |
| ime modela | TV101WXM-NU5 |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 142.32 × 228.2 × 4.3 (H×V×D) |
| zdravljenje | - |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| način dela | ADS, Normally Black, Transmissive |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| osvetlitev ozadja | 7S4P WLED , No Driver |
| uporablja za | Pad & Tablet |
| zaslon na dotik | Without |
