| PartNumber | TV101WUM-NL4 |
| Znamka | BOE |
| Velikost | 10.1 |
| Aplikacija | Pad & Tablet |
| Resolucija | 1200×1920 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka | BOE |
| model | TV101WUM-NL4 |
| velikost diagonale | 10.1 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1200(RGB)×1920 [WUXGA] 225PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 135.36(H)×216.576(V) mm |
| obris dim. | - |
| svetilnost | - |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | HADS, Normally Black, Transmissive |
| podpira barvo | 16.7M |
| Izvor svetlobe | WLED , 15K hours , W/O Driver |
| utež | - |
| namenjen za | Pad & Tablet |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | MIPI (4 data lanes) Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| F101NWN7-0 | IVO | 10.1 | 1920×1200 |
| HSD100IFW1-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW3-A00 | HannStar | 10.1 | 1024×600 |
| HT101WSB-100 | BOE | 10.1 | 1024×600 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
| N101L6-L0C | Innolux | 10.1 | 1024×600 |
| Q101IRE-GB1 | Innolux | 10.1 | 1280×800 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
| TV101WXM-NP0 | BOE | 10.1 | 1280×800 |
| TV101WXM-NP1 | BOE | 10.1 | 1280×800 |
