| PartNumber | TV097FMM-LB0-1SP0 |
| Znamka | BOE |
| Velikost | 9.7 |
| Aplikacija | Pad & Tablet |
| Resolucija | 1280×1752 |
| Sestava | a-Si TFT-LCD , Assem |
| Svetlost | |
| CR | 1200:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka | BOE |
| velikost diagonale | 9.7 inch |
| slikovnih pik | 1280(RGB)×1752 223PPI |
| aktivno območje | 145.344(H)×198.94(V) mm |
| območje okvirja | - |
| svetilnost | 320 cd/m² (Typ.) |
| smer pogleda | Symmetry |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| podpira barvo | 16.7M 70% NTSC |
| utež | 115g (Max.) |
| hitrost sličic | 60Hz |
| tip vmesnika | MIPI (4 data lanes) , 45 pins Connector |
| napajanje | 1.8/5.7/-5.7V (Typ.)(VDD/AVDD/AVEE) |
| okolju | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | TV097FMM-LB0-1SP0 |
| vrsta | a-Si TFT-LCD , Assembly |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 150.344(H)×208.29(V) mm |
| zdravljenje | Clear, Hard coating |
| kontrastno razmerje | 1200:1 (Typ.) (TM) |
| odzivni čas | 35 (Max.)(G to G) |
| način delovanja | - |
| Izvor svetlobe | WLED [9S4P] , 15K hours , W/O Driver |
| namenjen za | Pad & Tablet |
| plošča na dotik | In-Cell Touch |
