| PartNumber | TPM0501010P |
| Znamka | JDI |
| Velikost | 5.0 |
| Aplikacija | Mobile Phone |
| Resolucija | 1080×1920 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka | JDI |
| model | TPM0501010P |
| velikost diagonale | 5.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1080(RGB)×1920 [FHD] 445PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 61.641(H)×109.584(V) mm |
| obris dim. | 64.04(H)×116.52(V) ×1.48(D) mm |
| svetilnost | 450 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| način delovanja | IPS, Normally Black, Transmissive |
| podpira barvo | 16.7M 85% NTSC |
| Izvor svetlobe | WLED [7S2P] , W/O Driver |
| utež | TBD |
| namenjen za | Mobile Phone |
| hitrost sličic | 60Hz |
| plošča na dotik | In-Cell Touch |
| tip vmesnika | MIPI (4 data lanes) , 40 pins Connector |
| napajanje | 1.8/5.5/-5.5V (Typ.)(IOVCC/AVDD/AVEE) |
| okolju | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
