| PartNumber | TM057KDH01-41 |
| Znamka | TIANMA |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | 5S3P |
| Vmesnik | Parallel |
| znamka plošče | TIANMA |
| panelni model | TM057KDH01-41 |
| velikost plošče | 5.7" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 320(RGB)×240, QVGA, 70PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 115.2(W)×86.4(H) mm |
| odprtina okvirja | 118.2(W)×89.4(H) mm |
| velikost obrisa | 144(W)×104.6(H) ×12.8(D) mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| vidni kot | 70/70/70/60 (Typ.)(CR≥10) |
| način prikaza | TN, Normally White, Transmissive |
| najboljši pogled na | 12 o'clock |
| odzivni čas | 20 (Typ.)(Tr+Td) |
| barve zaslona | 262K 50% NTSC |
| tip svetilke | 5S3P WLED , 50K hours , Without Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | 160g (Typ.) |
| aplikacija | Industrial |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
