| PartNumber | TM050RDH03-00 |
| Znamka | TIANMA |
| Velikost | 5.0 |
| Aplikacija | Industrial Portable |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 600:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 7S2P |
| Vmesnik | Parallel |
| znamka plošče | TIANMA |
| panelni model | TM050RDH03-00 0 Compatible |
| velikost plošče | 5.0" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 800(RGB)×480, WVGA, 188PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 108(W)×64.8(H) mm |
| odprtina okvirja | 111.1(W)×67.9(H) mm |
| velikost obrisa | 120.7(W)×75.8(H) ×3.1(D) mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 250 cd/m² (Typ.) |
| kontrastno razmerje | 600:1 (Typ.) (TM) |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10) |
| način prikaza | TN, Normally White, Transmissive |
| najboljši pogled na | 12 o'clock |
| odzivni čas | 20 (Typ.)(Tr+Td) |
| barve zaslona | 16.7M 50% NTSC |
| tip svetilke | 7S2P WLED , 20K hours , Without Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | TBD |
| aplikacija | Industrial Portable Navigation MID UMPC MP3 PMP |
| signalni vmesnik | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
