| PartNumber | TCG121XGLPBPNN-AN40-S |
| Znamka | Kyocera |
| Velikost | 12.1 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1024×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 600:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | Kyocera |
| panelni model | TCG121XGLPBPNN-AN40-S |
| velikost plošče | 12.1" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1024(RGB)×768, XGA, 105PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 245.76(W)×184.32(H) mm |
| odprtina okvirja | 249.0(W)×187.5(H) mm |
| velikost obrisa | 260.5(W)×203(H) ×10.9(D) mm |
| površino | Antiglare |
| svetlost | 780 cd/m² (Typ.) |
| kontrastno razmerje | 600:1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način prikaza | AWV, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 18/12 (Typ.)(Tr/Td) |
| barve zaslona | 262K/16.2M 51% NTSC |
| tip svetilke | WLED , 50K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | 555g |
| aplikacija | Industrial Outdoor High Brightness |
| signalni vmesnik | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| AA121SJ23 | Mitsubishi | 12.1 | 800×600 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| HV121WX5-113 | HYDIS | 12.1 | 1280×800 |
| LQ121S1DC71 | SHARP | 12.1 | 800×600 |
| LQ121X1LH73 | SHARP | 12.1 | 1024×768 |
| LTD121C32S | TOSHIBA | 12.1 | 800×600 |
| LTD121EA3P | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXPD | TOSHIBA | 12.1 | 1280×800 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
