| PartNumber | TCG085WVLCF-G00 |
| Znamka | Kyocera |
| Velikost | 8.5 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | Parallel |
| proizvajalec | Kyocera |
| ime modela | TCG085WVLCF-G00 |
| velikost zaslona | 8.5 inch |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| število slikovnih pik | 800(RGB)×480 (WVGA) 109PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 184.8 × 110.88 (H×V) |
| obris (mm) | 210 × 134 × 11.1 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare |
| svetilnost | 320 cd/m² (Typ.) |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| vidni kot | 60/60/60/45 (Typ.)(CR≥10) |
| odgovor | 15/35 (Typ.)(Tr/Td) ms |
| dober pogled na | - |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 262K 49% NTSC |
| osvetlitev ozadja | WLED , 50K hours , No Driver |
| masa | TBD |
| uporablja za | Industrial |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | 4-wire Resistive Touch, G/G |
| vrsto signala | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
