| PartNumber | G085VW01 V1 |
| Znamka | AUO |
| Velikost | 8.5 |
| Aplikacija | IA |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 200 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TTL |
| znamka plošče | AUO |
| panelni model | G085VW01 V1 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 8.5 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 184.8×110.88 mm |
| oris | 222.7×135.4×12.5 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 200 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193150% |
| odzivni čas | 20/10 (Typ.)(Tr/Td) |
| vidni kot | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | TTL (1 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
