| PartNumber | R156B48-167-0101 |
| Znamka | No Brand |
| Velikost | 15.6 |
| Aplikacija | Laptop |
| Resolucija | 1366×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | 8S6P |
| Vmesnik | LVDS |
| znamka plošče | No Brand |
| panelni model | R156B48-167-0101 1 Compatible |
| velikost plošče | 15.6" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1366(RGB)×768, WXGA, 100PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 344.232(W)×193.536(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 359.3(W)×209.5(H) ×5.5(D) mm |
| površino | Glare (Haze 0%) |
| svetlost | 200 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| vidni kot | 45/45/20/40 (Typ.)(CR≥10) |
| način prikaza | TN, Normally White, Transmissive |
| najboljši pogled na | - |
| odzivni čas | 12 (Typ.)(Tr+Td) |
| barve zaslona | 262K 45% NTSC |
| tip svetilke | 8S6P WLED , 15K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| slog oblike | Wedge (PCBA Bent, T≥5.2mm) |
| aplikacija | Laptop |
| signalni vmesnik | LVDS (1 ch, 6-bit) , 40 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B156HTN04.0 | AUO | 15.6 | 1920×1080 |
| BT156GW01 V.4 | Innolux | 15.6 | 1366×768 |
| LTN156AT01-B01 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-H01 | Samsung | 15.6 | 1366×768 |
| LTN156AT17-D01 | Samsung | 15.6 | 1366×768 |
| N156B3-L02 | Innolux | 15.6 | 1366×768 |
| N156BGE-E42 | Innolux | 15.6 | 1366×768 |
| N156O6-L02 | Innolux | 15.6 | 1600×900 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
