| PartNumber | QV101WUB-N80 |
| Znamka | BOE |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1920×1200 |
| Sestava | CELL , a-Si TFT-LC |
| Svetlost | |
| CR | 900:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | |
| proizvajalec | BOE |
| velikost zaslona | 10.1 inch |
| število slikovnih pik | 1920(RGB)×1200 (WUXGA) 224PPI |
| aktivna površina (mm) | 216.806 × 135.504 (H×V) |
| površina okvirja (mm) | - |
| svetilnost | 0 (cd/m²) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| debelina stekla | - |
| barvna globina | 16.7M 72% NTSC |
| masa | - |
| hitrost osveževanja | 60Hz |
| ime modela | QV101WUB-N80 |
| vrsto zaslona | CELL , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 221.81 × 145.5 (H×V×D) |
| zdravljenje | Hard coating |
| kontrastno razmerje | 900 : 1 (Typ.) (TM) |
| način dela | ADS, Normally Black, Transmissive |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| transmisivnost | 3.85% (Typ.)(with Polarizer) |
| osvetlitev ozadja | No B/L |
| uporablja za | Industrial |
| zaslon na dotik | Without |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| CLAA101WB03 | CPT | 10.1 | 1366×768 |
| G101STN01.3 | AUO | 10.1 | 1024×600 |
| HSD100IFW3-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PUW1-A00 | HannStar | 10.1 | 1920×1200 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LP101WX2-SLA1 | LG Display | 10.1 | 1280×800 |
| LTN101AT03-801 | Samsung | 10.1 | 1366×768 |
| M101NWN8 R0 | IVO | 10.1 | 1366×768 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
