| PartNumber | PT236AT01-1 |
| Znamka | HKC |
| Velikost | 23.6 |
| Aplikacija | TV Sets |
| Resolucija | 1366×768 |
| Sestava | CELL , a-Si TFT-LC |
| Svetlost | |
| CR | 3000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | |
| proizvajalec | HKC |
| velikost zaslona | 23.6 inch |
| število slikovnih pik | 1366(RGB)×768 (WXGA) 66PPI |
| aktivna površina (mm) | 521.471 × 293.184 (H×V) |
| površina okvirja (mm) | - |
| svetilnost | 0 (cd/m²) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| debelina stekla | 0.50+0.50 mm |
| barvna globina | 16.7M 68% NTSC |
| masa | 500g (Typ.) |
| hitrost osveževanja | 60Hz |
| ime modela | PT236AT01-1 |
| vrsto zaslona | CELL , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 535.471 × 306.404 × 1.37 (H×V×D) |
| zdravljenje | Antiglare (Haze 3%), Hard coating (3H) |
| kontrastno razmerje | 3000 : 1 (Typ.) (TM) |
| način dela | FSA, Normally Black, Transmissive |
| odgovor | 9.5 (Typ.)(G to G) ms |
| transmisivnost | 6.0% (Typ.)(with Polarizer) |
| osvetlitev ozadja | No B/L |
| uporablja za | TV Sets |
| zaslon na dotik | Without |
