| PartNumber | PM070WM3 |
| Znamka | E Ink |
| Velikost | 7.0 |
| Aplikacija | DPF |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 330 |
| CR | 600:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | PVI |
| panelni model | PM070WM3 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 152.4×91.44 mm |
| oris | 166.3×105.3×11.8 mm |
| površino | Antiglare |
| svetlost | 330 cd/m² (Typ.) |
| kontrastno razmerje | 600:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 5/15 (Typ.)(Tr/Td) |
| vidni kot | 80/80/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 3S11PWLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 6-bit), 20 pins |
| vhodna napetost | 3.3V (Typ.) |
| rohs: | |
| aplikacija | DPF |
