| PartNumber | P101DEA-AZ0 |
| Znamka | Innolux |
| Velikost | 10.1 |
| Aplikacija | Pad & Tablet |
| Resolucija | 800×1280 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 4 |
| Vmesnik | MIPI |
| proizvajalec | Innolux |
| ime modela | P101DEA-AZ0 |
| velikost zaslona | 10.1 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 800(RGB)×1280 (WXGA) 150PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 135.36 × 216.576 (H×V) |
| obris (mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Glare (Haze 0%), Hard coating |
| svetilnost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Min.)(CR≥10) |
| odgovor | 35 (Max.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | AAS, Normally Black, Transmissive |
| barvna globina | 16.7M 60% NTSC |
| osvetlitev ozadja | 4 strings WLED , 15K hours , No Driver |
| masa | 175g (Max.) |
| uporablja za | Pad & Tablet |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | MIPI (4 data lanes) , Connector 40 pins |
| napajanje z napetostjo | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| maks. ocene | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
