| PartNumber | NL6448AC33-A1D |
| Znamka | NLT |
| Velikost | 10.4 |
| Aplikacija | Industrial |
| Resolucija | 640×480 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 900:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| proizvajalec | NLT |
| ime modela | NL6448AC33-A1D |
| velikost zaslona | 10.4 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 640(RGB)×480 (VGA) 76PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 211.2 × 158.4 (H×V) |
| obris (mm) | 227.3 × 177.5 × 9.8 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare |
| svetilnost | 370 cd/m² (Typ.) |
| kontrastno razmerje | 900 : 1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| odgovor | 18 (Typ.)(Tr+Td) ms |
| dober pogled na | - |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 262K |
| osvetlitev ozadja | WLED , 100K hours , With LED Driver |
| masa | 380g (Max.) |
| uporablja za | Industrial |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
