| PartNumber | NL6448AC33-A0D |
| Znamka | NLT |
| Velikost | 10.4 |
| Aplikacija | Industrial |
| Resolucija | 640×480 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 900:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | CMOS |
| znamka plošče | NLT |
| velikost plošče | 10.4" |
| resolucija | 640(RGB)×480, VGA, 76PPI |
| prikazno območje | 211.2(W)×158.4(H) mm |
| velikost obrisa | 246.5(W)×179.4(H) ×10(D) mm |
| svetlost | 500 cd/m² (Typ.) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| najboljši pogled na | - |
| barve zaslona | 262K 40% NTSC |
| pogostost | 60Hz |
| teža plošče | 390/435g (Typ./Max.) |
| signalni vmesnik | CMOS (1 ch, 6-bit) , 31 pins Connector |
| vhodna napetost | 3.3/5.0V (Typ.) |
| okolju | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| panelni model | NL6448AC33-A0D |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 900:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 3/15 (Typ.)(Tr/Td) |
| tip svetilke | WLED , 100K hours , With LED Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial |
