| PartNumber | NL3224AC35-09 |
| Znamka | NEC |
| Velikost | 5.5 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 400:1 |
| Barve | 262K |
| Osvetlitev ozadja | - |
| Vmesnik | |
| znamka plošče | NEC |
| velikost plošče | 5.5" |
| resolucija | 320(RGB)×240, QVGA, 72PPI |
| prikazno območje | 111.36(W)×83.52(H) mm |
| svetlost | - |
| vidni kot | - |
| najboljši pogled na | - |
| barve zaslona | 262K |
| pogostost | 60Hz |
| utež | - |
| panelni model | NL3224AC35-09 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| kontrastno razmerje | 400:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 5/25 (Typ.)(Tr/Td) |
| tip svetilke | |
| zaslon na dotik | Without |
| aplikacija | Industrial |
