| PartNumber | NL192108AC21-04 |
| Znamka | NLT |
| Velikost | 18.5 |
| Aplikacija | Industrial |
| Resolucija | 1920×1080 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | NLT |
| velikost zaslona | 18.5 inch |
| število slikovnih pik | 1920(RGB)×1080 (FHD) 119PPI |
| aktivna površina (mm) | 408.96 × 230.04 (H×V) |
| površina okvirja (mm) | 413.4 × 234.0 (H×V) |
| svetilnost | 400 cd/m² (Typ.) |
| vidni kot | 88/88/88/88 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| barvna globina | 16.7M 72% NTSC |
| masa | 1.55/1.70Kgs (Typ./Max.) |
| hitrost osveževanja | 60Hz |
| vrsto signala | LVDS (2 ch, 8-bit) , 30 pins Connector |
| napajanje z napetostjo | 5.0V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ime modela | NL192108AC21-04 |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 430.4 × 254.6 × 14 (H×V×D) |
| zdravljenje | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| odgovor | 12/13 (Typ.)(Tr/Td) ms |
| način dela | UA-SFT, Normally Black, Transmissive |
| osvetlitev ozadja | WLED , 50K hours , With LED Driver |
| uporablja za | Industrial |
| zaslon na dotik | Without |
