| PartNumber | NE173FHM-NZ1 |
| Znamka | BOE |
| Velikost | 17.3 |
| Aplikacija | Laptop Gaming |
| Resolucija | 1920×1080 |
| Sestava | Oxide TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 10S6P |
| Vmesnik | eDP |
| znamka plošče | BOE |
| panelni model | NE173FHM-NZ1 (BOE0884) |
| velikost plošče | 17.3" |
| vrsta plošče | Oxide TFT-LCD, LCM |
| resolucija | 1920(RGB)×1080, FHD, 127PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 381.888(W)×214.812(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 389.89(W)×238.31(H) ×3.5(D) mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način prikaza | ADS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 4 (Typ.)(G to G) |
| barve zaslona | 16.7M 100% sRGB |
| tip svetilke | 10S6P WLED , 15K hours , With LED Driver |
| pogostost | 240Hz |
| zaslon na dotik | Without |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| aplikacija | Laptop Gaming |
| signalni vmesnik | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B173HAN01.0 | AUO | 17.3 | 1920×1080 |
| B173HW01 V4 | AUO | 17.3 | 1920×1080 |
| G173HW01 V0 | AUO | 17.3 | 1920×1080 |
| LP173WF1-TLB3 | LG Display | 17.3 | 1920×1080 |
| LP173WF3-SLB1 | LG Display | 17.3 | 1920×1080 |
| LP173WF4-SPD1 | LG Display | 17.3 | 1920×1080 |
| LTN173HT02-D02 | Samsung | 17.3 | 1920×1080 |
| N173FGE-L21 | Innolux | 17.3 | 1600×900 |
| N173HCE-E31 | Innolux | 17.3 | 1920×1080 |
| N173HGE-L11 | Innolux | 17.3 | 1920×1080 |
