| PartNumber | N184H4-L01 |
| Znamka | Innolux |
| Velikost | 18.4 |
| Aplikacija | NBPC |
| Resolucija | 1920×1080 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | CMO |
| panelni model | N184H4-L01 2 Compatible model |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 18.4 inch |
| resolucija | 1920(RGB)×1080 , FHD |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 408.96×230.04 mm |
| oris | 422.5×248×6.5 mm |
| slog oblike | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 2/6 (Typ.)(Tr/Td) |
| vidni kot | 60/60/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 2 pcsCCFLWithout Driver |
| signalni vmesnik | LVDS (2 ch, 6-bit), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
| LTM184HL01 | Samsung | 18.4 | 1920×1080 |
| LTN184KT01-101 | Samsung | 18.4 | 1680×945 |
| LTN184KT01-F01 | Samsung | 18.4 | 1680×945 |
| LTN184KT01-S02 | Samsung | 18.4 | 1680×945 |
| LTN184KT02-T01 | Samsung | 18.4 | 1680×945 |
| N184H3-L02 | Innolux | 18.4 | 1920×1080 |
| N184H4-L01 | Innolux | 18.4 | 1920×1080 |
| N184H4-L04 | Innolux | 18.4 | 1920×1080 |
| N184H6-L02 | Innolux | 18.4 | 1920×1080 |
| HT140WXB-100 | BOE | 14.0 | 1366×768 |
| LP101WH1-TLA1 | LG Display | 10.1 | 1366×768 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| LQ164M1LD4CV | SHARP | 16.4 | 1920×1080 |
| LT121S1-101 | Samsung | 12.1 | 800×600 |
| LTN141X7-L06 | Samsung | 14.1 | 1024×768 |
| LTN154AT01-A01 | Samsung | 15.4 | 1280×800 |
| LTN156AT02-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT24-B01 | Samsung | 15.6 | 1366×768 |
| N133BGE-L31 | Innolux | 13.3 | 1366×768 |
