| PartNumber | LTM184HL01 |
| Znamka | Samsung |
| Velikost | 18.4 |
| Aplikacija | DMPC |
| Resolucija | 1920×1080 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 1000:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | SAMSUNG |
| panelni model | LTM184HL01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 18.4 inch |
| resolucija | 1920(RGB)×1080 , FHD |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno območje | 408.96×230.04 mm |
| oris | 443.4×266.5×4.3 mm |
| površino | Antiglare (Haze 1%), Antireflection |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193172% |
| odzivni čas | 16 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 12S6PWLEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (1 ch, 6-bit), 40 pins |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | DMPC |
