| PartNumber | N154I5-L02 |
| Znamka | Innolux |
| Velikost | 15.4 |
| Aplikacija | NBPC |
| Resolucija | 1280×800 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 400:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | CMO |
| panelni model | N154I5-L02 27 Compatible model |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 15.4 inch |
| resolucija | 1280(RGB)×800 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 331.2×207 mm |
| oris | 344×222×6.5 mm |
| slog oblike | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površino | Glare (Haze 0%), Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 400:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193145% |
| odzivni čas | 5/11 (Typ.)(Tr/Td) |
| vidni kot | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | LVDS (1 ch, 6-bit), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
| B154EW02 V7 | AUO | 15.4 | 1280×800 |
| LTN154BT02-004 | Samsung | 15.4 | 1440×900 |
| N154I2-L01 | Innolux | 15.4 | 1280×800 |
| N154I2-L02 | Innolux | 15.4 | 1280×800 |
| N154I2-L05 | Innolux | 15.4 | 1280×800 |
| N154I3-L03 | Innolux | 15.4 | 1280×800 |
| N154I4-L03 | Innolux | 15.4 | 1280×800 |
| N154I4-L04 | Innolux | 15.4 | 1280×800 |
| N154I5-L02 | Innolux | 15.4 | 1280×800 |
| N154I6-L03 | Innolux | 15.4 | 1280×800 |
| CLAA154WB04N | CPT | 15.4 | 1280×800 |
| LP133WX2-TLC3 | LG Display | 13.3 | 1280×800 |
| LP140QH1-SPA2 | LG Display | 14.0 | 2560×1440 |
| LP154WE3-TLA2 | LG Display | 15.4 | 1680×1050 |
| LTD121EQ3B | TOSHIBA | 12.1 | 1280×800 |
| LTN140AT07-401 | Samsung | 14.0 | 1366×768 |
| LTN154X3-L06-6 | Samsung | 15.4 | 1280×800 |
| LTN173KT01-H01 | Samsung | 17.3 | 1600×900 |
| LTN184KT02-T01 | Samsung | 18.4 | 1680×945 |
| N141C3-L02 | Innolux | 14.1 | 1440×900 |
