| PartNumber | MV185WHB-N20 |
| Znamka | BOE |
| Velikost | 18.5 |
| Aplikacija | Desktop Monitor |
| Resolucija | 1366×768 |
| Sestava | a-Si TFT-LCD, CELL |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | LVDS |
| znamka | BOE |
| model | MV185WHB-N20 |
| velikost diagonale | 18.5 inch |
| vrsta | a-Si TFT-LCD, CELL |
| slikovnih pik | 1366(RGB)×768 [WXGA] 84PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 409.8(H)×230.4(V) mm |
| obris dim. | 422.2(H)×244.1(V) ×1.32(D) mm |
| območje okvirja | - |
| zdravljenje | Antiglare (Haze 25%), Hard coating (3H) |
| svetilnost | 0 cd/m² |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 14 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način delovanja | HADS, Normally Black, Transmissive |
| debelina plošče | 0.50+0.50 mm |
| prepustnost | 6.0% (Typ.)(with Polarizer) |
| podpira barvo | 16.7M 72% NTSC |
| Izvor svetlobe | No B/L |
| utež | 327g (Typ.) |
| namenjen za | Desktop Monitor |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| detajl d-ic | COF Built-in 2 source chips |
| tip vmesnika | LVDS (1 ch, 8-bit) , 30 pins Connector |
| napajanje | 5.0V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
