| PartNumber | M270HTN02.2 CELL |
| Znamka | AUO |
| Velikost | 27.0 |
| Aplikacija | Desktop Monitor Gami |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD , CELL |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | V-by-One |
| znamka plošče | AUO |
| velikost plošče | 27.0" |
| resolucija | 1920(RGB)×1080, FHD, 81PPI |
| prikazno območje | 597.6(W)×336.15(H) mm |
| velikost obrisa | 608.3(W)×349.3(H) ×1.5(D) mm |
| svetlost | 0 cd/m² |
| vidni kot | 85/85/80/80 (Typ.)(CR≥10) |
| najboljši pogled na | 6 o'clock |
| globina stekla | 0.50+0.50 mm |
| barve zaslona | 16.7M 71% NTSC |
| pogostost | 144Hz |
| voznik ic | COF Built-in 6 source chips |
| teža plošče | 665g (Typ.) |
| signalni vmesnik | V-by-One 8 lane , 40 pins Connector |
| vhodna napetost | 12.0V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panelni model | M270HTN02.2 CELL |
| vrsta plošče | a-Si TFT-LCD , CELL |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 3.8/1.2 (Typ.)(Tr/Td) |
| transmisivnost | 5.3% (Typ.)(with Polarizer) |
| tip svetilke | No B/L |
| zaslon na dotik | Without |
| aplikacija | Desktop Monitor Gaming |
