| PartNumber | M220Z1-P03 |
| Znamka | Innolux |
| Velikost | 22.0 |
| Aplikacija | DMPC |
| Resolucija | 1680×1050 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No B/L |
| Vmesnik | LVDS |
| znamka plošče | CMO |
| panelni model | M220Z1-P03 |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 22.0 inch |
| resolucija | 1680(RGB)×1050 , WSXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 473.76×296.1 mm |
| oris | 485.26×307.6 mm |
| površino | Antiglare (Haze 25%), Hard coating (3H) |
| globina stekla | 0.70+0.70 mm |
| transmisivnost | 5.8% (Typ.)(with Polarizer) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit) |
| odzivni čas | 1.3/3.7 (Typ.)(Tr/Td) |
| vidni kot | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| signalni vmesnik | LVDS (2 ch, 8-bit), 30 pins |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | DMPC |
