| PartNumber | M140NWR8 R0 |
| Znamka | IVO |
| Velikost | 14.0 |
| Aplikacija | Laptop |
| Resolucija | 1366×768 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | IVO |
| velikost plošče | 14.0" |
| resolucija | 1366(RGB)×768, WXGA, 112PPI |
| prikazno območje | 309.399(W)×173.952(H) mm |
| svetlost | - |
| vidni kot | 45/45/15/35 (Typ.)(CR≥10) |
| najboljši pogled na | 6 o'clock |
| barve zaslona | 262K |
| pogostost | 60Hz |
| slog oblike | Slim (PCBA Bent, T≤3.0mm) |
| signalni vmesnik | eDP (1 Lane) Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panelni model | M140NWR8 R0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 8 (Typ.)(Tr+Td) |
| tip svetilke | WLED , 15K hours , With LED Driver |
| zaslon na dotik | Without |
| aplikacija | Laptop |
| B140HAN01.3 | AUO | 14.0 | 1920×1080 |
| B140RTN01.0 | AUO | 14.0 | 1600×900 |
| HB140WX1-200 | BOE | 14.0 | 1366×768 |
| LP140WH4-TLN1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLP1 | LG Display | 14.0 | 1366×768 |
| M140NWR1 R0 | IVO | 14.0 | 1366×768 |
| M140NWR2 R0 | IVO | 14.0 | 1366×768 |
| M140NWR2 R1 | IVO | 14.0 | 1366×768 |
| M140NWR2 R2 | IVO | 14.0 | 1366×768 |
| M140NWR4 R2 | IVO | 14.0 | 1366×768 |
