| PartNumber | LT104V3-100 |
| Znamka | Samsung |
| Velikost | 10.4 |
| Aplikacija | NBPC |
| Resolucija | 640×480 |
| Sestava | LCM |
| Svetlost | 70 |
| CR | 100:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TTL |
| znamka plošče | SAMSUNG |
| panelni model | LT104V3-100 1 Compatible model |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 10.4 inch |
| resolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 211.2×158.4 mm |
| oris | 264×180 mm |
| površino | |
| svetlost | 70 cd/m² (Typ.) |
| kontrastno razmerje | 100:1 (Min.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 20/40 (Typ.)(Tr/Td) |
| vidni kot | 48/48/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel RGB, 31 pins |
| vhodna napetost | 5.0V (Typ.)(VDD) |
| aplikacija | NBPC |
