| PartNumber | LSI490HN01-V |
| Znamka | SAMSUNG |
| Velikost | 49 |
| Aplikacija | Digital Signage |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, CELL |
| Svetlost | |
| CR | 4000:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | No |
| Vmesnik | LVDS |
| znamka | SAMSUNG |
| model | LSI490HN01-V |
| velikost diagonale | 49 inch |
| vrsta | a-Si TFT-LCD, CELL |
| slikovnih pik | 1920(RGB)×1080 [FHD] 45PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 1073.78(H)×604(V) mm |
| obris dim. | 1083.78(H)×615.5(V) ×1.3(D) mm |
| območje okvirja | - |
| zdravljenje | Antiglare (Haze 25%), Hard coating (2H) |
| svetilnost | 0 cd/m² |
| kontrastno razmerje | 4000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 6 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način delovanja | SPVA, Normally Black, Transmissive |
| debelina plošče | 0.40+0.50 mm |
| prepustnost | 6.79% (Typ.)(with Polarizer) |
| podpira barvo | 1.07B 99% sRGB |
| Izvor svetlobe | No B/L |
| utež | 1.80±0.18Kgs |
| namenjen za | Digital Signage |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| detajl d-ic | COF Built-in 6 source chips |
| tip vmesnika | LVDS (2 ch, 10-bit) , 51 pins Connector |
| napajanje | 12.0V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| HV490FHB-N80 | BOE | 49 | 1920×1080 |
| LC490DUJ-SGE3 | LG Display | 49 | 1920×1080 |
| LC490DUY-SHA1 | LG Display | 49 | 1920×1080 |
| LC490DUY-SHA2 | LG Display | 49 | 1920×1080 |
| LC490EGE-FHM1 | LG Display | 49 | 3840×2160 |
| LC490EQJ-SGK1 | LG Display | 49 | 3840×2160 |
| LC490EUE-FHM1 | LG Display | 49 | 1920×1080 |
| MT4851D01-1 | CSOT | 49 | 3840×2160 |
| ST4851D01-2 | CSOT | 49 | 3840×2160 |
