| PartNumber | HV490FHB-N80 |
| Znamka | BOE |
| Velikost | 49 |
| Aplikacija | LCTV |
| Resolucija | 1920×1080 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 1200:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No B/L |
| Vmesnik | LVDS |
| znamka plošče | BOE |
| panelni model | HV490FHB-N80 |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 49 inch |
| resolucija | 1920(RGB)×1080 , FHD |
| način prikaza | ADS, Normally Black, Transmissive |
| aktivno območje | 1073.78×604 mm |
| površino | Antiglare (Haze 1%) |
| transmisivnost | 6.3% (Typ.)(with Polarizer) |
| kontrastno razmerje | 1200:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193173% |
| odzivni čas | 8 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| signalni vmesnik | LVDS (2 ch, 8-bit), 51 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | LCTV |
