| PartNumber | LSC550HN06-W |
| Znamka | SAMSUNG |
| Velikost | 55 |
| Aplikacija | TV Sets |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD , CELL |
| Svetlost | |
| CR | 5000:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | No |
| Vmesnik | LVDS |
| znamka | SAMSUNG |
| velikost diagonale | 55 inch |
| slikovnih pik | 1920(RGB)×1080 [FHD] 40PPI |
| aktivno območje | 1209.6(H)×680.4(V) mm |
| območje okvirja | - |
| svetilnost | 0 cd/m² |
| smer pogleda | Symmetry |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| debelina plošče | 0.40+0.50 mm |
| podpira barvo | 1.07B 99% sRGB |
| utež | 2.33Kgs (Typ.) |
| hitrost sličic | 60Hz |
| detajl d-ic | COF Built-in 6 source chips |
| tip vmesnika | LVDS (2 ch, 10-bit) , 51 pins Connector |
| napajanje | 12.0V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| model | LSC550HN06-W |
| vrsta | a-Si TFT-LCD , CELL |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 1219.6(H)×692.9(V) ×1.3(D) mm |
| zdravljenje | Antiglare (Haze 2.3%), Hard coating (2H) |
| kontrastno razmerje | 5000:1 (Typ.) (TM) |
| odzivni čas | 6 (Typ.)(G to G) |
| način delovanja | SVA, Normally Black, Transmissive |
| prepustnost | 7.0% (Typ.)(with Polarizer) |
| Izvor svetlobe | No B/L |
| namenjen za | TV Sets |
| plošča na dotik | Without |
