| PartNumber | LSC550FN06 |
| Znamka | Samsung |
| Velikost | 55 |
| Aplikacija | LCTV |
| Resolucija | 3840×2160 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 4500:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | No B/L |
| Vmesnik | V-by-One |
| znamka plošče | SAMSUNG |
| panelni model | LSC550FN06 |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 55 inch |
| resolucija | 3840(RGB)×2160 , UHD |
| način prikaza | SVA, Normally Black, Transmissive |
| aktivno območje | 1209.6×680.4 mm |
| oris | 1219.6×691.7 mm |
| površino | Antiglare (Haze 2.3%), Hard coating (2H) |
| globina stekla | 0.50+0.50 mm |
| transmisivnost | 4.4% (Typ.)(with Polarizer) |
| kontrastno razmerje | 4500:1 (Typ.) |
| barve zaslona | 1.07B (8-bit + Dithering), sRGB99% |
| odzivni čas | 8 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| signalni vmesnik | V-by-One 8 lane, 51 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | LCTV |
