| PartNumber | LSC490HN05-W |
| Znamka | SAMSUNG |
| Velikost | 49 |
| Aplikacija | TV Sets |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD , CELL |
| Svetlost | |
| CR | 6000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | LVDS |
| znamka | SAMSUNG |
| velikost diagonale | 49 inch |
| slikovnih pik | 1920×1080(RGB) [FHD] 45PPI |
| aktivno območje | 1073.78(H)×604(V) mm |
| območje okvirja | - |
| svetilnost | 0 cd/m² |
| smer pogleda | Symmetry |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| debelina plošče | - |
| podpira barvo | 16.7M 99% NTSC |
| utež | 1.70Kgs (Typ.) |
| hitrost sličic | 60Hz |
| detajl d-ic | COF Built-in 2 source chips |
| tip vmesnika | LVDS (2 ch, 10-bit) , 51 pins Connector |
| napajanje | 12.0V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| model | LSC490HN05-W |
| vrsta | a-Si TFT-LCD , CELL |
| konfiguracijo | RGB Horizontal Stripe |
| obris dim. | 1078.78(H)×617.8(V) ×1.3(D) mm |
| zdravljenje | Antiglare (Haze 2.3%), Hard coating (2H) |
| kontrastno razmerje | 6000:1 (Typ.) (TM) |
| odzivni čas | 8 (Typ.)(G to G) |
| način delovanja | SVA, Normally Black, Transmissive |
| prepustnost | 6.9% (Typ.)(with Polarizer) |
| Izvor svetlobe | No B/L |
| namenjen za | TV Sets |
| plošča na dotik | Without |
