| PartNumber | LS050T1SX18 |
| Znamka | Sharp |
| Velikost | 5.0 |
| Aplikacija | Mobile Phone |
| Resolucija | 1080×1920 |
| Sestava | CG-Silicon, LCM |
| Svetlost | |
| CR | 1500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 6S2P |
| Vmesnik | MIPI |
| znamka plošče | Sharp |
| panelni model | LS050T1SX18 |
| velikost plošče | 5.0" |
| vrsta plošče | CG-Silicon, LCM |
| resolucija | 1080(RGB)×1920, FHD, 445PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 61.641(W)×109.584(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 63.64(W)×116.224(H) ×1.16(D) mm |
| površino | - |
| svetlost | 480 cd/m² (Typ.) |
| kontrastno razmerje | 1500:1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Min.)(CR≥10) |
| način prikaza | New Mode2, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 35 (Max.)(Tr+Td) |
| barve zaslona | 16.7M 95% NTSC |
| tip svetilke | 6S2P WLED , Without Driver |
| pogostost | 60Hz |
| zaslon na dotik | PCAP |
| teža plošče | 14.0g (Typ.) |
| aplikacija | Mobile Phone |
| signalni vmesnik | MIPI (4 data lanes) , 40 pins Connector |
| vhodna napetost | 1.8/5.5/-5.5V (Typ.)(VDDIO/AVDD/AVEE) |
| okolju | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
